INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 102 -
Table 5.7 Parameters about external measuring (HDI)
Function
code
Name
Description
Setting
P00.00
Speed control mode
0: SVC mode 0
1: SVC mode 1
2: Space voltage vector control mode
3: Closed-loop vector control mode
Note: If 0, 1 or 3 is selected, it is required to carry
out motor parameter autotuning first.
2
P00.01
Command running
channel
0: Keypad
1: Terminal
2: Communication
1
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P05.01
Function of S1
terminal
1: Forward running
1
P05.02
Function of S2
terminal
2: Reverse running
2
P20.15
Speed measuring
mode
0: Speed measuring by PG card/height measuring
on local
0
P25.03
Function of S7
terminal
64: Limit of forward run (upward)
64
P25.04
Function of S8
terminal
65: Limit of reverse run (downward)
65
P05.38
HDIA high-speed
pulse input function
2: Input through the encoder, used in combination
with HDIB
2
P05.44
HDIB high-speed
pulse input function
2: Input through the encoder, used in combination
with HDIA
2
P93.08
Enabling height
measuring
0–1
0: Disable
1: Enable internal measuring (motor encoder)
(in closed-loop mode, the encoder measures
2
