INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 101 -
Function
code
Name
Description
Setting
to measure heights.
P93.09
Mechanical
transmission ratio
0.01–300.00
10.00
P93.10
Suspension ratio
1–4
1
P93.11
Rope length
compensation
0.00m–50.00
0.00
P93.12
Cable diameter
0.1–100.0mm
10.0mm
P93.13
Per-layer turns of
drum winding
1–200
30
P93.14
Initial turns of drum
winding
0–P93.11 (Winding turns of the outermost layer in
upward limit)
0
P93.15
Initial diameter of
drum
100.0–2000.0mm
(Max. drum diameter in upward limit, including cable
thickness)
600.0mm
P93.16
Enabling
upward/downward
limit position check
0x00–0x11
Ones place:
0: The upward limit position is not reached.
1: The upward limit position is reached.
Tens place:
0: The downward limit position is not reached.
1: The downward limit position is reached.
Note: It is used to measure heights when there is no
upward/downward limit devices.
0x00
Height status check
P93.17
Total height
measured
0.00–655.35m (Total height measured from the
upward limit position to the downward limit position)
0.00m
P93.18
Measured height 1
-50.00m –655.35m (Using the downward limit
position as the reference point)
0.00m
P19.15
Measured height
0.00–655.35m
(Hook lowering distance using the upward limit
position as the reference point)
0.00m
P19.16
MSB of measured
height
0–65535
0
P19.17
LSB of measured
height
0–65535
0
