Goodrive350-19 series VFD Installing
- 35 -
S1
S2
COM
PW
+ 24V
COM
+ 24V
External power（PNP mode）
S1
S2
COM
PW
+ 24V
COM
+ 24V
Internal power（PNP mode）
Figure 4.21 PNP mode
4.4.3 Control circuit wiring of I/O extension card 2
+24V
PE
COM
S6
S5
PW
Extension terminal
S5
Extension terminal
S6
PT1+
PT2+
PT-
PE
(Externally connected
temperature resistor)
Goodrive350-19 series extension card
RO4C
RO4A
RO3C
RO3A
Relay 3 output
Relay 4 output
Temperature input
Extension terminal
S7
Extension terminal
S8
S8
S7
Figure 4.22 Control circuit wiring of I/O extension card 2
