INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Communication protocols
- 435 -
Function
Address
Data description
R/W
VFD identification
code
2103H
GD350-----0x01A0
R
Running frequency
3000H
0–Fmax(Unit: 0.01Hz)
Compatible
with CHF100A
and CHV100
communication
addresses
R
Set frequency
3001H
0–Fmax(Unit: 0.01Hz)
R
Bus voltage
3002H
0.0–2000.0V(Unit: 0.1V)
R
Output voltage
3003H
0–1200V(Unit: 1V)
R
Output current
3004H
0.0–3000.0A(Unit: 0.1A)
R
Rotating speed
3005H
0–65535(Unit: 1RPM)
R
Output power
3006H
-300.0–300.0%(Unit: 0.1%)
R
Output torque
3007H
-250.0–250.0%(Unit: 0.1%)
R
Closed-loop setting
3008H
-100.0–100.0%(Unit: 0.1%)
R
Closed-loop feedback
3009H
-100.0–100.0%(Unit: 0.1%)
R
Input state
300AH
000–3F
Corresponding to the local HDIB/
HDIA/ S4/ S3/ S2/ S1
R
Output state
300BH
000–0F
Corresponding to the local
RO2/RO1/HDO/Y1
R
Analog input 1
300CH
0.00–10.00V(Unit: 0.01V)
R
Analog input 2
300DH
0.00–10.00V(Unit: 0.01V)
R
Analog input 3
300EH
-10.00–10.00V(Unit: 0.01V)
R
Analog input 4
300FH
R
Read input of
high-speed pulse 1
3010H
0.00–50.00kHz(Unit: 0.01Hz)
R
Read input of
high-speed pulse 2
3011H
R
Read current step of
3012H
0–15
R
