INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Extension cards
-449-
Name
Model
Specification
single-contact output
I/O extension card 2
EC-IO502-00
• 4 digital inputs
• 1 PT100
• 1 PT1000
• 2 relay outputs: single-contact NO output
Note: The extension card has been built into the 7.5kW
and higher VFD models but it is optional for the VFD
models of lower than 7.5kW. For details, see section
4.4.3.
Bluetooth
communication card
EC-TX501-1
EC-TX501-2
• Supporting Bluetooth 4.0
• With INVT mobile app, you can set the parameters
and monitor the states of the VFD through Bluetooth
• The maximum communication distance in open
environments is 30 m.
• EC-TX501-1 is equipped with a built-in antenna and
applicable to molded case machines.
• EC-TX501-2 is configured with an external sucker
antenna and applicable to sheet metal machines.
WIFI communication
card
EC-TX502-1
EC-TX502-2
• Meeting IEEE802.11b/g/n
• With INVT mobile app, you can monitor the VFD
locally or remotely through WIFI communication
• The maximum communication distance in open
environments is 30 m.
• EC-TX501-1 is equipped with a built-in antenna and
applicable to molded case machines.
• EC-TX502-2 is configured with an external sucker
antenna and applicable to sheet metal machines.
PROFIBUS-DP
communication card
EC-TX503
• Supporting the PROFIBUS-DP protocol
Ethernet
communication card
EC-TX504
• Supporting Ethernet communication with INVT
internal protocol
• Can be used in combination with INVT upper
computer monitoring software INVT Studio
CANopen
EC-TX505
• Based on the CAN2.0A physical layer
