INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Extension cards
-450-
Name
Model
Specification
communication card
• Supporting the CANopen protocol
CAN master/slave
control
communication card
EC-TX511
• Based on the CAN2.0B physical layer
• Adopting INVT proprietary master/slave control
protocol
PROFINET
communication card
EC-TX509
• Supporting the PROFINET protocol
Sin/Cos PG card
EC-PG502
• Applicable to Sin/Cos encoders with or without CD
signals
• Supporting A, B, Z frequency-divided output
• Supporting pulse string reference input
UVW incremental
PG card
EC-PG503-05
• Applicable to differential encoders of 5 V
• Supporting the orthogonal input of A, B, and Z
• Supporting pulse input of phases U, V, and W
• Supporting frequency-divided output of A, B, and Z
• Supporting the input of pulse string reference
Resolver PG card
EC-PG504-00
• Applicable to resolver encoders
• Supporting frequency-divided output of
resolver-simulated A, B, Z
Multifunction
incremental PG card
EC-PG505-12
• Applicable to OC encoders of 5 V or 12 V
• Applicable to push-pull encoders of 5 V or 12 V
• Applicable to differential encoders of 5 V
• Supporting the orthogonal input of A, B, and Z
• Supporting the frequency-divided output of A, B, and
Z
• Supporting pulse string setting
Simplified
incremental PG card
EC-PG507-12
• Applicable to 5V or 24V OC encoders
• Applicable to 5V or 12V push-pull encoders
• Applicable to 5 V differential encoders
