INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 58 -
Function
code
Name
Setting
Remarks
P00.11
ACC time 1
10.0s
P00.12
DEC time 1
5.0s
P05.03
Function of S3 terminal
64
Upward position limit
P05.04
Function of S4 terminal
5
Fault reset
P05.24
Lower limit value of AI1
0.20V
0.00V–P05.26. Adjust the value
according to the actual situation.
P05.28
Input filter time of AI1
0.100s
0.000s–10.000s
P05.38
HDIA high-speed pulse
input function
2
Input through the encoder
P05.44
HDIB high-speed pulse
input function
2
Input through the encoder
P06.03
RO1 output selection
49
Brake output
P06.04
RO2 output selection
5
VFD fault
P20.15
Speed measuring mode
1
Measuring the speed through HDIA
and HDIB
P90.04
Enabling brake-oriented
logic
1
The brake is controlled by the VFD.
P90.05
Enabling forward torque
for reverse-running
start/stop
0x01
Enable forward torque for
reverse-running start/stop
P90.14
Forward brake release
torque
50.0%
Corresponding to the motor rated
torque
P90.15
Reverse brake release
torque
50.0%
Corresponding to the motor rated
torque
P90.16
Forward brake release
frequency
1.00Hz
P90.17
Reverse brake release
frequency
1.00Hz
P90.18
Forward brake closing
frequency
1.00Hz
P90.19
Reverse brake closing
frequency
1.00Hz
