Goodrive350-19 series VFD Commissioning
- 62 -
terminal functions according to the actual wiring. The recommended analog reference is 0V–10V.
5.8.2 Commissioning procedure
1. Check the wiring and ensure the wiring is proper.
2. Set P00.18=1.
3. Set motor nameplate parameters in P02.
4. Set P00.15=2. The keypad displays "-ΓUN-". Press the RUN key to perform static autotuning.
5. Set P90.00=12 to select the open-loop controlled winching function macro.
6. Perform low-speed trial running.
5.8.3 Macro parameters (P90.00=12)
Table 5.4 Parameter settings for the open-loop vector controlled winching application macro
(recommended analog reference 0V–10V)
Function
code
Name
Setting
Remarks
P00.00
Speed control mode
1
SVC 1
P00.01
Command running
channel
1
Terminal
P00.06
Setting channel of A
frequency command
1
AI1
P00.07
Setting channel of B
frequency command
0
Keypad
P00.11
ACC time 1
10.0s
P00.12
DEC time 1
5.0s
P05.03
Function of S3 terminal
64
Upward position limit
P05.04
Function of S4 terminal
5
Fault reset
P05.24
Lower limit value of AI1
0.20V
0.00V–P05.26. Adjust the value
according to the actual situation.
P05.28
Input filter time of AI1
0.100s
0.000s–10.000s
P06.03
RO1 output selection
49
Brake output
P06.04
RO2 output selection
5
VFD fault
P90.04
Enabling brake-oriented
logic
1
The brake is controlled by the VFD.
P90.05
Enabling forward torque
for reverse-running
start/stop
0x01
Enable forward torque for
reverse-running start/stop
P90.14
Forward brake release
torque
50.0%
Corresponding to the motor rated
torque
P90.15
Reverse brake release
50.0%
Corresponding to the motor rated
