INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 63 -
Function
code
Name
Setting
Remarks
torque
torque
P90.16
Forward brake release
frequency
2.00Hz
P90.17
Reverse brake release
frequency
2.00Hz
P90.18
Forward brake closing
frequency
2.00Hz
P90.19
Reverse brake closing
frequency
2.00Hz
Table 5.5 Parameter settings for the open-loop vector controlled winching application macro (using
analog reference -10V–10V)
Function
code
Name
Setting
Remarks
P00.00
Speed control mode
1
SVC 1
P00.01
Command running
channel
1
Terminal
P00.06
Setting channel of A
frequency command
2
AI2
P00.07
Setting channel of B
frequency command
0
Keypad
P00.11
ACC time 1
10.0s
P00.12
DEC time 1
5.0s
P05.03
Function of S3 terminal
64
Upward position limit
P05.04
Function of S4 terminal
5
Fault reset
P05.29
Lower limit value of AI2
-10.00V
-10.00V–P05.31
P05.30
Corresponding setting of
lower limit of AI2
100.0%
-300.0%–300.0%
P05.31
Intermediate value 1 of
AI2
-0.10V
P05.29–P05.33
P05.32
Corresponding setting of
intermediate value 1 of
AI2
0.0%
-300.0%–300.0%
P05.33
Intermediate value 2 of
AI2
0.10V
P05.31–P05.35
P05.34
Corresponding setting of
intermediate value 2 of
0.0%
-300.0%–300.0%
