INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 75 -
Function
code
Name
Description
Default
monitored current, it is considered
that the brake is not closed, and the
action specified by P90.34 is
performed. If the present current is
greater than the brake monitoring
current threshold, an action is
performed depending on the actual
frequency. If the actual frequency is
lower than the forward braking
frequency in forward running or the
actual frequency is lower than the
reverse braking frequency, it is
considered that the brake has been
closed, and a fault needs to be
reported.
P90.32
Brake feedback exception delay
(brake feedback detection time)
0.00–20.000S
1.000s
P90.33
Brake monitoring current
0.0%–200.0%
100.0% corresponding to the motor
rated current
100.0%
P90.34
Enabling speed reference under
brake status error
0–1
0: Disable (Report the brake
feedback fault directly)
1: Enable (Report the brake feedback
alarm simultaneously)
0
P90.35
Speed reference under brake
status error
0.00–50.00Hz
5.00Hz
P90.37
Brake selection for
forward/reverse switchover
0–1
0: Perform switchover without braking
1: Perform switchover with braking
0
P93.00
Brake slip speed threshold
1.00–5.00Hz
1.00Hz
P93.01
Brake slip
0.000–5.000s
The value 0 indicates brake slip is not
detected, while a non-zero value
indicates brake slip is detected.
0.500s
