INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 78 -
power balance.
Master setting parameters:
Function
code
Name
Description
Setting
P06.00
HDO output type
0: Open collector high-speed pulse output
1: Open collector output
0
P06.16
HDO high-speed pulse
output
0–47
2: Ramp reference frequency
2
Slave setting parameters:
Function
code
Name
Description
Setting
P00.06
Setting channel of A
frequency command
0–15
4: High speed pulse HDIA
4
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P08.30
Reduction ratio of
droop control
0.00–50.00Hz
1.00hz
2. Terminal master/slave mode b
The master adopts the speed control mode and sends the torque current to the slave HDIA terminal
through the HDO terminal. The slave adopts the torque control mode and the torque reference is set
by the HDIA terminal.
Master setting parameters:
Function
code
Name
Description
Setting
P06.00
HDO output type
0: Open collector high-speed pulse output
1: Open collector output
0
P06.16
HDO high-speed pulse
output
0–47
22: Torque current (relative to three times the
motor rated current)
22
Slave setting parameters:
