l LEVEL 1:the events are logged in a single field at control unit level and the additional information are:
detection field, detection distance (in mm) in access, and detection field at exit.
Format:
CONTROL UNIT Detection access (field #n, distance mm)
CONTROL UNIT Detection exit (field #n)
l LEVEL 2 / LEVEL 3 / LEVEL 4 The events are logged:

o
in a single field at control unit level and the additional information are: detection field, detection
distance (in mm) in access, and detection field at exit

o
at sensor level and the additional information read by the sensor are: detection distance (in mm) in
access, and detection field at exit.
Format:
CONTROL UNIT #k Detection access (field #n, distance mm)
SENSOR #k Detection access (distance mm)
CONTROL UNIT Detection exit (field #n)
SENSOR #k Detection exit
7.3 INFOevents
7.3.1 System Boot
Every time the system is powered up, the event is logged reporting the incremental count of the boot from the
beginning of the life of the device.
Format: System Boot #n
Example:
0 2020/11/18 16:47:25 [INFO] CONTROL UNIT SYSTEMBOOT #60
7.3.2 System configuration
Every time the system is configured, the event is logged reporting the incremental count of the configuration from
the beginning of the life of the device.
Format: System configuration #3
Example:
20 2020/11/18 16:47:25 [INFO] CONTROL UNIT System configuration #3
7.3.3 Factory reset
Every time a factory reset is required, the event is logged.
Format: Factory reset
Example:
20 2020/11/18 16:47:25 [INFO] CONTROL UNIT Factory reset
7. Maintenance and troubleshooting
