Ioline 300 - Visual Reference Guide

Figure 1. Front view of the 300 System and a close-up photo of the port and power swith on the back of the machine.
Visual Reference Guide
viii
A. Left end cover
B. Dust cover
C. Carriage (design may
vary)
D. Adhesive sheet, mounted
E. Right end cover
F. Keypad
G. Tray (removeable)
H. Origin (starting point)
I. Thumb nuts (2)
J. Table (non-removeable)
K. Leg (2)
L. Power switch
M. Serial port
N. USB port
O. Power connector
KEY
A
C
F
H
I
M
L
J
K
B
D
G
E
N O
