Ion Technologies IT- DS05-S User Manual

IONTECH
®
IT-DS EDI Modules
1 Introduction
This section contains the following instructions:
 IT-DS module overview - Brief introduction to components and models
 Using this Manual - How to use this Manual
 Precautions - Precautions to prevent personal injury or equipment damage during
installation
1.1
IT-DS Module Overview
IT-DS Modules are designed to be installed in either single module or multiple module Continuous
Deionization IT-DS systems. Their compact state-of-the-art design assures ease of
installation, maintenance, and service. The module sizes are designed in optimal flow
configurations stated below to ensure cost effective water system integration.
Table 1-1: Model numbers and nominal flow rates.
Moduel Number Nominal Flow Description
IT- DS05-S 2 gpm [0.44 m
3
/hr] Single IT-DS Type – 4 Cell
IT- DS10-S 5 gpm [1.1 m
3
/hr] Single IT-DS Type – 10 Cell
IT- DS20-S 9 gpm [2.0 m
3
/hr] Single IT-DS Type – 18 Cell
IT- DS30-S 15 gpm [3.3 m
3
/hr] Single IT-DS Type – 30 Cell
IT- DS50-S 22.5 gpm [5.1 m
3
/hr] Single IT-DS Type – 45 Cell
For more information on the IT-DS module specifications and flow rates, see Appendix A of this
Manual.
Figure 1-1 Side View IT-DS Module
6 IT-DS MAN Rev 0
