TIGER XT Instrument User Manual V1.2
Pioneering Gas Sensing Technology. Page 11 of 71 ionscience.com
1) Alarm LEDs/Torch
2) Probe assembly
3) Display screen
6) Battery Pack
7) Charging Contacts
8) Sensor Cover
9) Pump Outlet
10) USB Port (Type B)
1
2
3
4
5
4) Keypad
5) Instrument body
6
7
8
9
10
