TIGER XT Instrument User Manual V1.2
Pioneering Gas Sensing Technology. Page 56 of 71 ionscience.com
Replacement of Non-rechargeable Batteries
BATTERY REPLACEMENT: NEVER REPLACE PRIMARY ALKALINE BATTERY CELLS
WHILE IN A POTENTIALLY EXPLOSIVE OR HAZARDOUS LOCATION. USE ONLY
ENERGIZER EN91 LR6 BATTERIES.
Fitting batteries or connecting the Battery Pack with the wrong polarity may
result in damage to the instrument.
WEEE REGULATIONS
Dispose of used batteries in accordance with all local and national safety and
environmental requirements.
Inlet Probe Assembly
All parts of the probe assembly can be replaced if they become damaged or contaminated with use.
To replace the O-ring (5/OV-02) use a sharp scalpel and cut the damaged O-ring enduring you are
causing no damage to the Filter Clamp (912220). Take your new O-ring (5/OV-02) and stretch over
the Filter Clamp (912220) into place.
2 Filter Housing Cap (912221)
