TIGER XTL Instrument User Manual V1.0
Pioneering Gas Sensing Technology. Page 28 of 56 ionscience.com
• Permanently on
• On in low ambient light
• On for limited time
Enter time for the limited time option in the field provided (1 - 99 seconds).
Sound
The following options are available:
• Key press sounds
• Audible alarms
• “Crescendo”, i.e. the volume of the low level alarm sound increases as the upper alarm
level is approached
• Alarm Latch: alarms continue to sound, even if the gas level falls below the threshold, until
the Esc key is pressed. If Alarm Latch is not set, user set alarms conditions are triggered and
reset based on the alarm thresholds in the user settings.
Volume is adjusted using the slider.
Vibrate
Use to set your TIGER XTL to vibrate under alarm conditions.
Calibration
Use this area to define your Custom Calibration parameters.
