iPA ALPHA MUTT - Body Exploded View

15.1 Body Exploded View
ITEM
PART #
QTY
DESCRIPTION
1
FAS-0150
15
10-32 X 3/8 PHILLIPS
2
005600-3R
1
5600 TOP
3
5600-DRAWER-AS
1
5600 DRAWER
4
005600-11R
1
5600 DRAWER PANEL
5
005600-2R
1
5600 BACK
6
5600-FACE-AS
1
5600 FACE ASSEMBLY
7
5600-DOOR-AS
1
5600 DOOR ASSEMBLY
8
FAS-0036
3
¼-20 X 3/8 HEX CAP
9
5600-BUMPER
2
DOOR BUMPER
10
FAS-0161
2
#6 X 3/8 SHEET METAL SCREW
11
FAS-0040
9
10-32 X 3/8 HEX CAP
12
7900AP-10
2
5700 EXHAUST FITTING
13
5600-SLDBASE-AS
1
5600 SLIDING BASE
14
FAS-148
4
5/16-18 X ½ HEX CAP
15
FAS-0160
4
5/16 SPLIT LOCK WASHER
16
FAS-0159
4
5/16 FENDER WASHER
17
FAS-0143
8
10-32 X ½” FLAT HEAD HEX SOCKET
