15.2 Face Exploded View
ITEM
PART #
QTY
DESCRIPTION
1
007900K-57
4
4-40 HEX NUT
2
PCB0022-AS2
1
DIGITAL AIR PCB
3
PCB0021-AS2
1
CONTROL BOARD
4
N/A
8
LCD STANDOFF
5
SW0002B
2
LONG ENCODER COLLAR
6
007900K-11B
2
COLLAR O RING
7
N/A
8
NYLON BOARD STANDOFF
8
N/A
8
NYLON WASHER
9
N/A
2
DUAL LINE LCD
10
005600-1R
1
5600 FACE
11
N/A
3
PUSH BUTTON PCB
12
7900K-32A
8
6-32 X 3/8 PHILLIPS
13
PBS-0004GR
9
PUSH BUTTONS
14
SW0002A-JN
2
COLLAR NUT
15
007900K-2
2
ENCODER KNOB
16
N/A
4
14MM FLAT WASHER
17
7900AP-26-AS
2
MILLED AIR BULKHEAD
18
FAS-0125
2
6-32 X 1/8 PHILLIPS
19
7900K-8Z
1
7 WAY ROUND SOCKET
20
7900K-23
2
5/16-18 X 1 PHILLIPS
21
005700-OBD2M
1
OBD2 MALE SOCKET
22
005700-14R
1
OBD BRACKET
23
FAS-0009
2
5/16 FLAT WASHER
24
FAS-0008
2
5/16 SPLIT LOCK WASHER
25
FAS-0007
2
5/16-18 HEX NUT
