15.3 Side-Panel Exploded View
ITEM
PART #
QTY
DESCRIPTION
1
FAS-0144
1
10-32 THIN NYLON LOCKNUT
2
RLY16
1
POWER RELAY
3
7900K-57
2
4-40 NUT
4
7900K-59
2
#4 SPLIT LOCK WASHER
5
7900AP-7
2
#4 FLAT WASHER
6
BUZ-AS2
1
PIEZO
7
FAS-0007
2
5/16-18 NUT
8
FAS-0008
2
5/16 LOCK WASHER
9
FAS-0006
2
5/16 FLAT WASHER
10
CBL-USB3FTMF
1
3’ USB CORD
11
CBL-USB18MF
1
18” USB CORD
12
7900K-20
2
6-32 HEX NUT
13
7900K-21
2
#6 EXT TOOTH LOCK WASHER
14
7900AP-26-AS
1
MILLED BULKHEAD ¼” NPT FITTING
15
MUT-EXTPWR2-AS
1
EXT POWER
16
7900K-22
2
6-32 X ½ PHILLIPS
17
9005A-RES-AS
1
7 WAY ROUND RESISTOR PACK
18
7900K-23
2
5/16-18 X 1 PHILLIPS
19
005600-4R
1
ACCESS PANEL
20
FAS-0150
8
10-32 X 3/8 PHILLIPS
21
MUT-REG-AS
1
PRESSURE REGULATOR
22
7900AP-2
2
6-32 X 1 PHILLIPS
23
7900K-85
1
30A FUSE
24
FAS-0040
1
10-32 X 3/8 HEX CAP
25
7900K-18
1
FUSE HOLDER
26
009008-SN
1
ID TAG
27
7900K-13A
1
CHASSIS GROUND
28
7900K-18A
1
FUSE CAP
29
RSW0012-L
1
SEALED POWER SWITCH
