iPA ALPHA MUTT - Page 95

15.4 Storage Drawer Exploded View
ITEM
PART #
QTY
DESCRIPTION
1
VEL-0004
1
VELCRO STIP
2
5700A-PLCPLT-AS
1
PLC ENCLOSURE ASSEMBLY
3
7900K-57
4
4-40 HEX NUT
4
7900K-59
4
#4 LOCK WASHER
5
MUT-SOLF-AS
1
SOLENOID F AS.
6
MUT-SOLG-AS
1
SOLENOID G AS.
7
005600-8R
1
DRAWER TOP
8
005600-CHAINBRK
1
2PC BRACKET SET
9
005600-CHAIN
1
ECHAIN 24 LINKS
10
FAS-0144
6
10-32 NYON LOCKNUT
11
005600-10R
1
DRAWER FRAME
12
FAS-0143
6
10-32 X ½ FLAT HD SOCKET
13
FAS-0162
4
4-40 X 1/8 PHILLIPS
14
005600-GROMMET
2
CABLE GROMMET
15
5700-MNTRT-AS2
1
RAM MOUNT ASSEMBLY WITH CABLE
16
5600-FOAM
1
DRAWER FOAM
17
CBL-USBMF6FT
1
6’ USB CABLE
18
005600-SLIDE
1
14” DRAWER SLIDE PAIR
19
FAS-0143
4
8/32 X ¼ PHILLIPS TRUSS
20
005600-9R
1
DRAWER
21
FAS-0154
4
8/32 X 7/16 FLAT HD PHILLIPS
22
FAS-0151
4
8/32 X 3/32 HEX NUT
23
FAS-0152
4
#8 INT TOOTH LOCK WASHER
15-9
