15.6 Slide-Out Base Exploded View
ITEM
PART #
QTY
DESCRIPTION
1
FAS-0140
4
¼-20 X 1-1/2” FLAT HEAD
2
005600-SLIDE2
1
16” UNIT SLIDE PAIR
3
FAS-0143
8
10-32 X ½” FLAT HEAD HEX SOCKET
4
FAS-0146
2
¼-20 X 5/8” FLAT HEAD HEX SOCKET
5
ALU00016-MIL
2
ANGLE BRACKET
6
FAS-0145
8
#10 WASHER SS
7
FAS-0144
8
10-32 NYLON LOCK NUT
8
FAS-0141
4
5/16-18 X 1” ROUND HEAD HEX SOCKET
9
ALU0002-15MIL
1
REAR BRACE
10
9066-4
4
PLASTIC END CAPS
11
FAS-0142
4
12-24 X 3/8” PHILLIPS ROUND
12
FAS-0045
4
¼” WASHER
13
RBF0002
4
Ø 1.5” X 1” FEMALE THREAD RUBBER FEET
14
FAS-0027
6
¼” NYLON LOCK WASHER
15
ALU00017-MIL
1
CROSS BRACE
16
ALU0002-17MIL
1
FRONT BRACE
