GB
Brush installation
Single-brush machine:
position the brush underneath the head, in the centre (Fig. 7); switch the machine on. Pressing
the ATTACH/RELEASE button once after starting the machine releases the brushes, pressing the
button a second time activates automatic brush attachment; the button is only enabled when all the
functions are deactivated (suction motor and brushes).
Double-brush machine:
position the brushes underneath the head on both sides (Fig. 8), the brushes should rest on the
brush centering device in the centre of the head; switch the machine on.
Pressing the ATTACH/RELEASE button once after starting the machine releases the brushes,
pressing the button a second time activates automatic brush attachment; the button is only enabled
when all the functions are deactivated (suction motor and brushes).
8
7
18
