IPC CT80 - TECHNICAL INFORMATION; General description; Parts of the machine

GB
TECHNICAL INFORMATION
General description
This machine is a scrubber drier for sweeping, washing and drying at, horizontal, smooth or mod-
erately rough, even and obstacle free oors in civil and industrial premises.
The scrubber drier spreads a solution of water and detergent in the correct concentration on the
oor and then scrubs it to remove the dirt. By carefully choosing the detergent and brushes (or
abrasive disks) from the wide range of accessories available, the machine can be adapted to a wide
range of combinations of types of oor and dirt.
A suction system incorporated in the machine dries the oor after washing by means of the low
pressure generated in the dirty water tank by the suction motor. The squeegee connected to the
tank collects the dirty water.
Parts of the machine
The machine comprises the main parts described below (g. 1).
► The water/detergent tank (g. 1, ref. 1) contains and carries the mixture of clean water and
cleaning product.
► The dirty water tank (g. 1, ref. 2) collects the dirty water picked up from the oor after
washing;
► Control panel (g. 1, ref. 3).
► Head assembly (g. 1, ref. 4), the main element comprises the brushes/rollers which dis-
tribute the detergent solution onto the oor and remove the dirt.
► Squeegee assembly (g. 1, ref. 5): wipes and dries the oor by collecting the water.
1
4
3
2
5
