31
4.2.1. Washing the evaporator
Wear protective gloves during the follow-
ing operations.
HOW TO ACCESS THE EVAPORATOR:
Inordertocleantheinsideoftheevaporator,use a
flat-blade screwdriver to loosen the screw located at the
right side of the fan-holding panel and turn it to the left.
4.2.2. Emptying condensation
The models with a built-in condensing unit are equipped
with a special tray to gather condensation and wash
water. It is at the bottom part of the appliance.
Empty and clean the tray periodically, pulling it out from
beneath the appliance using the appropriate handle.
Do not use sharp objects.
METHODS FOR CLEANING EVAPORATOR
In order to clean the evaporator, a brush can be used with
a vertical movement along the direction of the aluminium
flaps.
When finished, close the fan-holding panel carrying out
the operations inversely.
