6.2 Specifications
page 34 IGX/IGB Series Operation Manual No. 0202A
IGB Series
Item Contents
Model Name IGB-60 IGB-150
<OIML Approved>
Weighing Capacity 60 kg / 150 lb 150 kg / 300 lb
Graduation 0.02 kg / 0.05 lb 0.05 kg / 0.1 lb
Accuracy 1/3000
Weighing Platter 550 mm (L) x 400 mm (W)
Exterior Material
Display: ABS resins
Display pole: Aluminum die-cast
Weighing platter: Stainless (SUS304)
Display Angle Adjust
Angle adjustable from the horizon (0°) to the front, Knob locking method
Weight 16.0 kg (excluding batteries)
Environmental Condition
Temperature from -5°C to +40°C, Relative humidity 80%RH (max.)
without condensation
Power Source
Two dray batteries (not attached to machine), or optional AC adapter
[Battery Life]
Conditions: No option, Temperature 20°, Relative humidity 60%RH
Two “D” size alkaline batteries (Approx. 500H continuous use)
Power Consumption 2.4 to 6VDC: 25mA
Display
x LCD
Numerics: 6 digits, Height 25 mm
Mark: Battery. Zero point, Now subtracting tare, Stable, Weight unit
(kg･lb), Over, Under, Accept
Tare Subtraction
x Key-in tare
x Preset tare
Preset Function
[Program Mode] 10 PLUs from PLU 1 to PLU 10
(Tare weight, Upper limit, Lower limit)
Upper Limit Range More than the lower limit, within 5 digits (99999)
Lower Limit Range Less than the upper limit (5 digits in case of the upper limit = 0)
Auto Power Off [Setup Mode] None/10min./ 20min./ 30min./ 40min./ 50min./ 60min.
Auto Preset Call-up
[Setup Mode] Function “Yes”/”No” selection
(PLU 1 is called up when the power is ON.)
Battery Check Mode Yes
Buzzer No
ON/OFF Switch
Option AC adapter (Dealer option)
