6.2 Specifications
IGX/IGB Series Operation Manual No. 0202A page 33
6
APPENDIX
6.2 SPECIFICATIONS
IGX Series
Item Contents
Model Name IGX-60 IGX-150
<OIML Approved>
Weighing Capacity 60 kg / 150 lb 150 kg / 300 lb
Graduation 0.02 kg / 0.05 lb 0.05 kg / 0.1 lb
Accuracy 1/3000
Weigh Platter 550mm (L) x 400mm (W)
Exterior Material
Display: ABS resins
Display pole: Aluminum die-cast
Weighing platter: Stainless (SUS304)
Display Angle Adjust
Angle adjustable from the horizon (0°) to the front, Knob locking method
Weight 16.8kg
Environmental Condition
Temperature from -5°C to +40°C, Relative humidity 80%RH max.
without condensation
Power Source
The required transformer is provided for each 100VAC, 120VAC, 220VAC,
or 240VAC.
Power Consumption
120VAC: 46 mA
Display
x VFD
Numerics: 5 + 1/2 digits, Height 29 mm
Mark: Zero point, Now subtracting tare, Stable
x LED
Over, Under, Accept
Tare Subtraction
x Key-in tare
x Preset tare
Preset Function
[Program Mode] 10 PLUs from PLU 1 to PLU 10
(Tare weight, Upper limit, Lower limit)
Upper Limit Range More than the lower limit, within 5 digits (99999)
Lower Limit Range Less than the upper limit (5 digits in case of the upper limit = 0)
Auto Power Off [Setup Mode] None/10min./ 20min./ 30min./ 40min./ 50min./ 60min.
Auto Preset Call-up
[Setup Mode] Function “Yes“ / “No“ selection
(PLU 1 is called up when the power is ON.)
Battery Check Mode No
Buzzer Yes
ON/OFF Switch
Option
