LED Flashes 5 ×
Cause The Open power limit has been activated.
The door system has stopped in the door
Open direction.
Remedy
▶
Remove the triggering obstacle.
If the door system stopped before the
Open end-of-travel position without a
discernible reason:
▶
Check the door mechanics or the
tension of the toothed belt.
– Delete the door data if required
(see section11.2). Then teach in
the door system again (see
section5.1).
Or
– Readjust the tension of the
toothed belt (see section9.1).
Acknow-
ledgement
▶
Give an impulse via
– an external button,
– a hand transmitter button,
– the T button.
The door closes.
LED Flashes 6 ×
Cause System error/malfunction in operator
system
Remedy
▶
Delete the door data if required (see
section11.2). Then teach in the door
system again (see section5.1).
If the operator error occurs again:
▶
Replace the operator.
Acknow-
ledgement
▶
Give an impulse via
– an external button,
– a hand transmitter button,
– the T button.
The door opens (reference run).
LED Flashes 7 ×
Cause The operator has not been taught in (no
error, only a notification).
Remedy /
acknow-
ledgement
▶
Provide an impulse and initiate a
learning run by
– an external button,
– a hand transmitter button,
– the T button.
The door closes.
LED Flashes 8 ×
Cause The operator does not have a reference
point (no error, only a notification)
Remedy /
acknow-
ledgement
▶
Provide an impulse and initiate a
reference run by
– an external button,
– a hand transmitter button,
– the T button.
The door opens.
Note Normal behaviour following a power
failure, if
ō no door data is available,
ō the door data has been deleted,
ō the last door position is not known.
