iStorage datAshur Pro User Manual

#18
iStorage datAshur
®
Pro Manual – v 1.6
www.istorage-uk.com
24. How to configure the datAshur Pro with Windows OS
In the event that hacking detection has been triggered by entering the incorrect PIN 10 times in succession or the drive
has been reset, all data on the drive will be lost forever.
Once a New User PIN has been created, the datAshur Pro will need to be initialised and formatted.
To initialise your datAshur Pro, do the following:
1. Create a New User PIN (see section 4).
2. Unlock the datAshur Pro by entering the New User PIN and connect to a computer’s USB port.
Instructions LED LED State
1. Press and hold down number 7 (seven) button and then
press the KEY button and release buttons
(7 & )
/
Red and Green LED’s blink alternately
2. Within 10 seconds begin to Press the number 9 button
three times (treble click) (999)
/
Red and Green LED’s continue to blink
alternately
3. Press and hold down number 7 (seven) button and then
press the KEY button and release buttons
(7 & )
Red LED fades out to complete the reset process
4. Proceed by clicking on Format disk.
Select FAT32 or NTFS depending on your needs, enter a Volume Label and click Start.
3. The computer should notify the user with the following message:

iStorage datAshur Pro Specifications

General

Encryption	AES-XTS 256-bit hardware encryption
Storage Capacity	8GB, 16GB, 32GB, 64GB, 128GB, 256GB, 512GB
Interface	USB 3.2 Gen 1
Operating System Compatibility	Windows, macOS, Linux, Chrome OS, Android
Authentication	PIN code
Compliance	FIPS 140-2 Level 3
Special Features	Read-only mode
Operating Temperature	0°C to 60°C
Storage Temperature	-20°C to +85°C (-4°F to +185°F)
Certifications	FIPS 140-2 Level 3
Power Supply	Bus powered
Security Features	brute force protection
