iStorage diskAshur DT2 User Manual

#25
www.istorage-uk.com
iStorage diskAshur DT
2
®
Manual – v 1.8
31. How to check Firmware in User Mode
1. In User mode press and hold down “3 + 8” until
GREEN and BLUE LEDs blink together
Solid GREEN LED will change to blinking
GREEN and BLUE LEDs
2. Press the “UNLOCK” button and the following happens;
a. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
b. RED LED blinks indicating the integral part of the firmware revision number.
c. GREEN LED blinks indicating the fractional part.
d. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
e. LEDs return to solid GREEN
To check the firmware revision number, first enter the “User Mode” as described in section 20. Once the drive is in User
Mode (solid GREEN LED) proceed with the following steps.
For example, if the firmware revision number is ‘1.2’, the RED LED will blink once (1) and the GREEN LED will blink two (2)
times. Once the sequence has ended the RED, GREEN & BLUE LED’s will blink together once and then return to a solid BLUE
LED.

iStorage diskAshur DT2 Specifications

General

Type	HDD
HDD size	- \
HDD speed	- RPM
Read speed	225 MB/s
Write speed	223 MB/s
HDD capacity	12000 GB
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-B
Thunderbolt technology	No
USB data transfer rates	12, 480, 5000 Mbit/s
Maximum data transfer rate	5000 Mbit/s
User guide	Yes
Cables included	USB
Sustainability certificates	RoHS
Certification	FCC, CE, WEEE
Product color	Black, Grey
Cable lock slot type	Kensington
Mobile operating systems supported	Android
AC adapter output voltage	12 V
Harmonized System (HS) code	84717050

Weight and Dimensions

Depth	112 mm
Width	185.5 mm
Height	43.5 mm
Weight	1238 g
