Programming Codes iTherm
®
280 Programmer’s Guide
Page 168 Rev C 28-07764
[ESC] y <6> and <7> enable and disable the inquire process.
These commands are not processed as they are received, but are
buffered then processed. The buffering process allows inquire commands
sent after a disable to be answered. In addition, inquires sent after an
enable may not be answered. (See additional notes 3 and 4 on the next
page).
The printer has a resident OCR
MA font. It is defined and
mapped per ANSI X3.111-1986. Once mapped into a code page, it can
be removed by issuing an [ESC] y <12> command or a code-page select
command.
Note 5: In EPOS mode, the [ESC] y command is active.
[ESC] ~ Extended Configuration and Control
ASCII [ESC] ~ <n>
Hexadecimal 1BH 7EH <n>
Decimal <27> <126> <n>
IPCL none
EPOS [ESC] ~ <n>
Description The [ESC] ~ <n> commands are extended diagnostics commands. They
must all be preceded with an enabling command. These commands (in
general) are not intended to be used by the end user.
To Next Page
