iTherm
®
280 Programmer’s Guide Programming Codes
28-07764 Rev C Page 215
0 Off 00H <0> Pin 3 is Low
On (03H) (3) Pin 3 is High
1 – 7 Off 00H <0> Not used; fixed to Off
Table 40 Peripheral Status (<n> = 0, 48)
Function Transmit Paper Sensor Status
ASCII [ESC] v
Hexadecimal 1BH 76H
Decimal <27> <118>
Description The [ESC] v command has been replaced by the [GS] r command. The [ESC] v
command transmits paper status has been replaced by the [GS] r command.
The iTherm
®
280 return paper status as specified below. If the Electronic Journal
is enabled, Journal Low and Out are supported by this command
Electronic Journal Disabled
Bit Off/On Hex Decimal Status
0,1 Off 00 <0> Receipt Paper present
On 02H <2> Receipt Paper Low or not present
2,3 Off 00 <0> Cover is closed
On 04H <4> Cover is open
4 Off 00 <0> Not used, fixed Off
5 Off 00 <0> Slip is present
On 04H <4> Slip is not present
6 ON 20H <64> Fixed On
7 Off 00 <0> Not used, fixed Off
Electronic Journal Enabled
Bit Off/On Hex Decimal Status
0 Off 00H <0> Journal Space adequate > 8K
On 01H <1> Journal Space Low < 8K
1 Off 00 <0> Receipt Paper present
On 02H <2> Receipt Paper Low or not present
2 Off 00 <0> Cover is closed
On 04H <4> Cover is open
3 Off 00 <0> Journal is active and not full (Cover
Closed)
On 08H <8> Journal Full and has been disabled (or
Cover Open)
4 Off 00 <0> Not used, fixed Off
5 Off 00 <0> Slip is present
On 04H <4> Slip is not present
6 ON 20H <64> Fixed On
7 Off 00 <0> Not used, fixed Off
Table 41 Paper Status
