Unicode Encoding Example
3 Byte output Example
Hex Character Code: FA11
FA 11 - Original Hex Code(s)
11111010 000100001 - Converted to Binary
1111 1010 00 0100001 - Underlined by section (ending of output byte)
Section A Section B Section C
4 digits 6 digits 6 digits
1110 1111 10 101000 10 010001 - 3 (8bit) Binary numbers
EF A8 91 - 3 Hex Bytes to Output
<239> <168> <145> - 3 decimals to output
