1. General
1.1. Designated use
MUPASZ 710 plus is designated for operation as a multi-function bay control device in MV grids,
with grounded or insulated neutral point, and in compensated grids.
Fig. 1.1.1 The view of MUPASZ 710 plus.
The device can work in grids with frequency 50 or 60 Hz.
The MUPASZ 710 plus bay controller may have up to 8 bay types (profiles) implemented
which may be freely modified and adapted to the user’s requirements. Logic function
simulator is included. The user may also redesign implemented bay views and usage of 16
three-colour signaling diodes.
MUPASZ 710 plus works with ELF application used to design individual bay operation logic,
parameterization of protections, to configuration, to read measurements and events, and
to control device operation in service mode.
The regular 36 months warranty period may be extended to 60 or 120 months.
