User manual
Strona 8 z 36 IU_M710P_MANUAL_05i00_ENG
1.3. Functionality and accessories
Logic - Used to edit operational logic of the device, utilizes: protections, automatic functions, logic
gates, comparators, timers, flip-flops, registers, event blocks, etc. Available via ELF program.
Simulator - Used to carry out simulations of designed logic and preview analog-digital signals in the
profile schematics. Forcing of input signals and measurement values can be carried out using data
saved in COMTRADE format. Available via ELF program.
Bay view – Allows editing graphic representation of bay schematics, visible in the device, via ELF
program.
Freely programmable diodes - 16 freely programmable tricolour diodes. The Elf program allows their
editing: assignment of functions to be signaled, signaling order, description, colours and display
mode.
Set points - Used to preview and edit parameters: nominal values, protections, automatic functions,
control and monitoring systems, autodiagnostics; grouped into sets of set points.
Texts - Used to preview texts predefined in the device, in supported languages, and to edit editable
texts. Available via ELF program.
Selected counters - Used to configure Selected Event Counters window.
Selected measurements - Used to configure Selected Measurements window.
Selected MODBUS records - Used to map MODBUS registers.
Configuration - Used to preview and edit configuration parameters of the device, i.a. system clock,
communication ports, user interface.
Log - Used to preview events logged in the device.
Event counters - Each event defined in the device has a16-bit counter assigned. Used to preview
their values in Event Counter window.
States - Used to preview system states, digital inputs and outputs, signal diodes, communication
ports, user login information.
Measurements - Used to preview measurements, along with their status.
UM – User Manager controls and identifies users access to functions of the device.
RALG - Algorithm register - used to preview, in textual and graphical form, of algorithm operating
states, of e.g. protections, automatic functions, switches.
Service - Group of service parameters available to users with service privilege.
