4. A connector is crimped properly when the top of the movable yellow center (1) is flush with
the top of the connector body (2).
Warning! Crimping the connector forces some sealant out of connector. The
sealant protects the inside of the connector against insects, moisture, and other
contaminants. The sealant may cause minor eye and skin irritation. Avoid eye
contact. Avoid prolonged or repeated skin contact. Contact Itron Support for
Safety Data Sheets (SDS).
5. After the 500W ERT module to register or meter wire connections are completed, arrange
the connectors in a single file.
08 January 2020 815-0006-01 Itron, Inc. Page 46 of 48
Template 7 îCompleting Gel-cap Connections Using the Itron Splice Kit
