ITT Goulds Pumps NM 3196 i-FRAME User Manual

Figure 7: Example of a proper lifting method with a strap secured around the frame adapter
Figure 8: Example of offset overhead motor mount pump proper lifting method
2.3 Storage guidelines
2.3.1 Pump storage requirements
Storage requirements depend on the amount of time that you store the unit. The normal packaging is
designed only to protect the unit during shipping.
Length of time in storage Storage requirements
Upon receipt/short-term (less than six
months)
• Store in a covered and dry location.
•
Store the unit free from dirt and vibrations.
Long-term (more than six months) • Store in a covered and dry location.
•
Store the unit free from heat, dirt, and vibrations.
• Rotate the shaft by hand several times at least every three months.
2.3 Storage guidelines
Model NM 3196 i-FRAME Installation, Operation, and Maintenance Manual 19

ITT Goulds Pumps NM 3196 i-FRAME Specifications

General

Model	NM 3196 i-FRAME
Category	Water Pump
Type	Centrifugal Pump
Connection Type	Flanged
i-FRAME	Yes
Seal Type	Mechanical Seal
