ITT Goulds Pumps NM 3196 i-FRAME User Manual

catastrophic failure occurs. The i-ALERT® monitor allows customers to identify potential problems before
they become costly failures. It tracks vibration, temperature, change in electromagnetic field and run-time
hours and wirelessly syncs the data with the i-ALERT Gateway or with a smart phone or tablet using i-
ALERT® mobile app.
More information available on https://www.i-alert.com/products/
Current IOMs are available at http://www.gouldspumps.com/en-us/tools-and-resources/literature/ - and -
resources/literature/ IOMs, https://www.i-alert.com/ or your local ITT Goulds Pumps Sales Rep.
Alarm mode
The condition monitor enters alarm mode when either vibration or temperature limits are exceeded over
two consecutive readings within a user defined period. Alarm mode is indicated with red flashing LED.
Table 6: Temperature and vibration limits
Variable Limit
Temperature 100°C | 195°F Surface Temperature
Vibration 100% increase over the baseline level
Battery life
The i-ALER
T® Condition Monitor battery is replaceable.
The battery life is not covered as part of the standard pump warranty.
This table shows the average condition monitor battery life under normal and alarm-mode operating con-
ditions.
Condition monitor operational state Battery life
Normal operating and environmental conditions Three to five years
Alarm mode One year
3.3 Nameplate information
Important information for ordering
Every pump has nameplates that provide information about the pump. The nameplates are located on
the casing and the bearing frame.
When you order spare parts, identify this pump information:
•
Model
• Size
• Serial number
• Item numbers of the required parts
Item numbers can be found in the spare parts list.
Refer to the nameplate on the pump casing for most of the information. See Parts List for item numbers.
Nameplate types
Nameplate Description
Pump casing Provides information about the hydraulic characteristics of the pump.
Pump The formula for the pump size is: Discharge x Suction - Nominal Maximum Impeller Diameter in
inches.
(Example: 2x3-8)
3.3 Nameplate information
24 Model NM 3196 i-FRAME Installation, Operation, and Maintenance Manual

ITT Goulds Pumps NM 3196 i-FRAME Specifications

General

Model	NM 3196 i-FRAME
Category	Water Pump
Type	Centrifugal Pump
Connection Type	Flanged
i-FRAME	Yes
Seal Type	Mechanical Seal
