Dimensions and clearance
6 720 802 419 (2012/06) en
13
6.2 E6 - E11
Fig. 7
Fig. 8
All dimensions are stated in mm.:
[1] Electrical connections
[2] Collector circuit out
[3] Collector circuit in
[4] Return, hot water heater
[5] Flow, hot water heater
[6] Return heating system
[7] Flow heating system
≥100 ≥100
≥400
1520
6 720 641 855-03.1I
E
F
D
C
A
B
105 189213
600
47
168
48
645
88
6
7
4
5
1
3
2
6 720 647 043-33.1I
20
800
