General
6 720 802 419 (2012/06) en
7
3General
3.1 Information about the heat pump
C6-C11 are heat pumps with integrated hot water heaters.
E6-E11 are heat pumps designed to be supplemented with an external
hot water heater.
3.2 Application area
The heat pump must only be used in a closed hot water heating system
according to BS EN 12828.
Other forms of use are not permitted. We take no responsibility for
damage occurring due to non-permitted use.
3.3 Type overview
[C] Heat pump (with integrated hot water heater)
[E] Heat pump (without integrated hot water heater)
[6-11] Heating output 6...11 kW
3.4 Type plate
The type plate is located on the roof plate of the heat pump. Information
about the heat pump's output, part number, serial number and date of
manufacture is stated there.
3.5 Transport and storage
The heat pump should always be transported and stored in an upright
position. However, the heat pump may be tilted temporarily, but must
not be laid down.
The outer cover plates should be removed to avoid damage if the heat
pump is transported without the supplied transport pallet.
The heat pump must not be stored at below zero temperatures.
3.6 Positioning the heat pump
B The heat pump is placed indoors, on a level and stable surface that
withstands a weight of at least 500 kg.
B Adjust the rubber feet so the heat pump does not lean.
B The ambient temperature around the heat pump must be between
+10 °C and +35 °C.
B The installer should take sound propagation into consideration when
positioning the heat pump.
B Make sure there is a floor drain in the room where the heat pump is
installed.
3.7 Checks before installation
B Installation of the heat pump should be performed by a qualified
installer.
B Before the heat pump is commissioned, the heating system, hot water
cylinder and the collector circuit system, including the heat pump,
must be filled and vented.
B Check that all pipe connections are intact and have not shaken loose
during transportation.
B Wiring should be kept as short as possible to protect the system from
downtime, for example during a thunderstorm.
B Heat pump installation, energy drilling and collector installation must
follow applicable regulations.
3.8 Checklist
1. Position the heat pump on an even base. Adjust the height using the
adjustable feet.
2. Install the incoming and outgoing pipes for the heat pump, as well as
the expansion vessel.
3. Fit the filling unit, particle filters and valves.
4. Connect the heating unit to the heating system.
5. Install the outdoor sensor and possible room sensors.
6. Fill and vent the heating and collector systems before commissioning.
7. Carry out the external connections.
8. Connect the heating installation to the power supply.
9. Commission the heating installation by making all the necessary
settings on the control panel.
10. Check the heating installation after commissioning.
11. Top up more collector circuit fluid, if required.
Only qualified installers may carry out the installation.
The installer must follow applicable rules and regulations
and recommendations from the supplier.
C 6 7911
E 6 7911
Table 2 Type overview
Each heat pump installation is unique. The following
checklist will give you a general description of how the
installation should be carried out.
