Dimensions and clearance
6 720 802 419 (2012/06) en
12
6Dimensions and clearance
6.1 C6 - C11
Fig. 5
Fig. 6
All dimensions are stated in mm.:
[1] Collector circuit in
[2] Collector circuit out
[3] Cold water in
[4] Electrical connections
[5] Flow heating system
[6] Hot water out
[7] Return heating system
≥100 ≥100
≥300
1800
6 720 641 570-10.1I
6 720 647 043-32.3I
600
46
52
190
645
119 100 173 6781
5
3
7
4
211
1
2
20
800
6
