15 Menu overview
The top menu level for installers is:
• Room temperature
• Hot water
• Holiday
• Energy measurements
• Timers
• External control
• Installer
• Additional heat
• Safety functions
• General
• Alarms
• Access level
• Return to factory settings
• Program version
Access level 0 = Customer
Access level 1 = Installer
HP x = Heat pump 1 or 2 / Compressor 1 or 2
Room temperature Access level
Circuit 1 Heating Type of heating system 1
Highest permitted flow temperature T1
1
Lowest permitted flow temperature T1
1
Heat curve
0
Heat curve hysteresis heat pump x
Maximum
Minimum
Time factor
1
1
1
Room sensor
Room temperature influence
Acknowledge room sensor
1
1
Room temperature program
Active program
View/edit active program
Room temperature normal
Temperature increase/decrease (no room sensor)
Setting temp. increase/decrease (no room sensor)
> Limit value for left or right end point
> Change when much colder/warmer
> Change when colder/warmer
Room temperature influence (no room sensor)
Room temperature exception
Copy to all heating circuits
0
0
0
0
1
1
1
1
0
0
0
Circuit 2, 3...
(option)
Mixing valve mode 1
Type of heating system
1
Highest permitted flow temperature T1
1
Lowest permitted flow temperature T1
1
Heat curve
0
Room sensor
As Circuit 1 Heatings 0, 1
Room temperature program
As Circuit 1 Heating minus Copy to all heating circuits 0, 1
Regulator settings
P constant
I constant
D constant
Minimum PID signal
Maximum PID signal
Mixing valve running time
Mixing valve fully closed
Mixing valve start closing
1
1
1
1
1
1
1
1
General Summer/winter operation Winter operation
Outdoor temperature limit for change over
Delay before change over to winter operation
Delay before change over to summer operation
Direct start limit for winter operation
0
0
1
1
1
Maximum operating time for heating at hot water demand
1
Minimum outdoor temperature
1
Table 25 Room temperature menus
Hot water Access level
Acknowledge hot water sensor T3 1
Extra hot water Extra hot water duration
Extra hot water stop temperature
0
0
Table 26 Hot water menus
