Technical information
6 720 802 419 (2012/06) en
23
7.3.3 E6 - E11
Unit E6 E7 E9 E11
Mode fluid/water
Heat output (B0/W35)
1)
1) With internal pump acc to EN 14511
kW 5,0 6,6 8,7 10,2
Heating output (B0/W45)
1)
kW 4,8 6,2 8,3 9,6
COP (B0/W35)
1)
- 3,51 3,82 3,84 3,97
COP (B0/W45)
1)
- 2,82 2,97 3,15 3,17
Heat transfer fluid
Nominal flow (delta_T = 3K
2)
)
2) Glycol
l/s 0,20 0,41 0,50 0,62
Permitted external pressure drop
2)
kPa 47 43 80 91
Max. pressure bar 4
Contents (internal) l 5
Operating temperature °C -5... +20
Connection (Cu) mm 28
Compressor
Type Mitsubishi scroll
Weight cooling agent R407c
3)
3) Global Warming Potential, GWP
100
= 1526
kg 1,6 1,6 1,8 2,4
Max. pressure bar 31
Heating system
Nominal flow (delta_T = 7K) l/s 0,20 0,25 0,31 0,38
Min. flow temperature °C 20
Max. flow temperature °C 65
Max. permitted operating pressure bar 3
Hot water content l 7
Connection (Cu) mm 22
Values for electrical connection
Electrical supply 230V 1N~50Hz
Fuse, slow; with electric additional heat 3/6/9 kW A 25/40/63 32/40/63 32/50/63 40/50/63
Nominal power consumption compressor (B0/W35) kW 1,17 1,48 1,78 2,09
Max. current with soft starter A <35
Enclosure class IP X1
General
Permitted ambient temperature °C 10...35
Sound level
4)
4) Acc to EN 3743-1
dBA 47 50 52 48
Dimensions (height x depth x width) mm 600 x 645 x 1520
Weight (without packaging) kg 150 155 165 175
Table 13 Technical information
