External control Access level
Heat pump x External input 1, 2 Invert input 1
Block additional heat 100% at trigged power guard 1
Max output additional heat at trigged power guard 1
Block compressor x 0
Block additional heat 0
Block heating at tripped underfloor temperature limiter 0
Block heating 0
Room temperature 0
Block hot water production 0
Start collector circuit pump 1
Alarm at low pressure in collector circuit 1
External input circuit 2, 3... Invert input 1
Block heating at tripped underfloor temperature limiter 1
Block heating 0
Room temperature 0
Table 30 External control menus
Installer Access level
General Anti-seizure mode Day of the week
Start time
1
1
Highest permitted flow temperature T1
1
Operating mode
1
Groundwater
Groundwater
Compressor start delay groundwater
1
1
Display light switch off delay 1
Time for reset of access level
1
Heat pump x capacity 1
Connected I/O boards Shows which circuit boards are connected and their program version 1
Compressor working area Outdoor stop function activated 1
Generated energy Heating 1
Hot water
1
Operating times and
consumptions
Displays the total operating times of the compressor and additional heat.
Short term measurements can be made.
1
Temperatures All connected temperature sensors are displayed and can also be corrected. 1
Programmable outputs 1
Inputs Shows the status of all connected inputs (pressostats, motor cut-out,
external inputs, etc.)
1
Outputs Manual operation of and status of constituent components (pumps, valves,
additional heat, alarm indication etc.)
1
Circulation pumps Heating circuit pump G1 Operation alternative 1
Heat carrier pump G2
Operation alternative
Pump speed E2x
Regulator settings
1
1
1
Collector circuit pump G3
Operation alternative 1
Table 31 Installer menus
Additional heat Access level
Additional heat general Start delay 1
Allow additional heat timer during energy supply cut-off
1
Additional heat only
1
Block additional heat
1
Maximum outdoor temperature for additional heat
1
Table 32 Additional heat menus
