Operation Manual – ITW GSE 7400 Battery Powered GPU
90 kVA
Transportation and Installation
Document No. 575.410DB Page 35 of 195
4.6 Transportation
Fig. 4.6.1 Access for Forklift, Truck, or Similar (same placement on Previous/ Paillard trailer)
NOTE
Do not lift by crane
The four tie-down rings shown in the can be used to fasten the ITW GSE 7400 during transport.
The rings have been designed to be drawn in the direction of the ring, approx. 30° downwards.
Fig. 4.6.2 Tie-Down Rings (same placement on Previous / Paillard trailer)
