6.5.2 I/O Configuration
6.5.2.1 1 x 400 Hz output
Inputs
Outputs
No
Function
Ref.
No
Function
Ref.
No
Function
Ref.
No
Function
Ref.
1
Connector 1
PTC
X7:I1
15
Not Used
X16:I15
1
Not Used
X27:O1
15
Not Used
X27:O15
2
Not Used
X8:I2
16
Grid
Connector
Interlock
X11:I16
2
Not Used
X27:O2
16
+ I/O (F6)
X18:O16
3
Not Used
X16:I3
17
External
EPO *
X9:I17
3
Run/Charge
Beacon
X23:O3
17
PM -INV
X21:O17
4
Not Used
X16:I4
18
Start/Reset
Output 1
X28:I18
4
Warning
Beacon
Input
X23:O4
18
PM +INV
X21:O18
5
Smoke
Detector
X31:I5
19
Stop
Output 1
X28:I19
5
Not Used
X23:O5
19
Soft Start
X21:O19
6
Plug 1
Inserted
X7:I6
20
Not Used
X28:I20
6
Not Used
X23:O6
20
Coil Control
Output 1
X4:O20
7
Not Used
X8:I7
21
Not Used
X28:I21
7
Control
battery
X18:O7
21
Not Used
X5:O21
8
Grid Voltage
Present
X10:I8
22
Not Used
X28:I22
8
Not Used
X27:O8
22
NBPT
Control
X3:O22
9
Busbar
Temperature
X20:I9
23
Not Used
X28:I23
9
Not Used
X27:O9
23
50/60 Hz
Q1 Coil
X12:O23
10
Transf. TL °
X24:I10
24
Not Used
X28:I24
10
Not Used
X27:O10
24
Not Used
X6:O24
11
Transf. TH °
X24:I11
25
GPS Unit
X13:I25
11
Not Used
X27:O11
25
GPS Unit
X13:O25
12
Not Used
X16:I12
12
Smoke
Detector
X31:O12
26
GPS Unit
X13:O26
13
GPU Enable
X28:I13
13
Not Used
X27:O13
27
GPS Unit
X13:O27
14
Not Used
X28:I14
14
Not Used
X27:O14
28
GPS Unit
X13:O28
*
When using the External EPO, please remember to remove SW4 on the Interface Board (A2)
Note
Please refer to the schematic for further information.
