Operation Manual – ITW GSE 7400 Battery Powered GPU
90 kVA
Operator’s Instructions
Document No. 575.410DB Page 74 of 195
Black Box – Menu Structure (Continued)
Battery 4
Voltage: 391 V
Current: 0.0 A
State of Charge: 96.2 %
Mode: Discharge
Status Code: 0
 Back / Next/Prev
Battery 3
Voltage: 400 V
Current: 0.0 A
State of Charge: 96.1 %
Mode: Discharge
Status Code: 0
 Back / Next/Prev
Battery 2
Voltage: 400 V
Current: 0.5 A
State of Charge: 96.3 %
Mode: Discharge
Status Code: 0
 Back / Next/Prev
Battery 1
Voltage: 400 V
Current: 0.0 A
State of Charge: 96.2 %
Mode: Discharge
Status Code: 0
 Back / Next/Prev
Input / Outp ut Port Status
I 1 2 3 4 5 6 7 8 9 10 11 12 13 14
N
15 16 17 18 19 20 21 22 23 24 25
O 1 2 3 4 5 6 7 8 9 10 11 12 13 14
U
T
15 16 17 18 19 20 21 22 23 24 25 26 27 28
