Iveco N67 MNA M15

31
INSTALLATION DIRECTIVE
N45 MNA M10
N67 MNA M15
MAY 2006
CAUTION
To assure the utmost reliability and safety while underway, all installations must be provided with the following alarm indica-
tions:
(SATA) high coolant temperature
(SBPO) low oil pressure
It is also recommended that the following indications be present:
(SAC) presence of water in the fuel pre-filter
(SIFA) clogged air filter
(SS) alternator fault
Functions of the JD terminals
PIN Description Electric level
OFF Indication ON Indication
1 Module power supply Positive (+B)
2 EDC lamp power supply Power supply positive (+B)
3 EDC Fault indication High (+B) Low (ground)
4 Pre-heating light power supply Power supply positive (+B)
5 Pre-heating indication High (+B) Low (ground)
6 Pre-lubrication indication Open circuit High (+B)
7 Engine start Power supply positive (+B) while starting
8 Sound alarm inhibition Negative (ground) during the request
9 Module power supply Negative (ground)
10 Buzzer power supply Negative (ground) during the emission of sound
11 Clogged oil filter indication Open circuit Low (ground)
12 Clogged oil vapor filter indication Open circuit Low (ground)
13 Clogged air filter indication Open circuit Low (ground)
14 Clogged fuel filter indication Low (ground) Open circuit
15 Alternator fault indication High (+B) Low (1 to 3 V)
16 Low engine coolant level indication Open circuit Low (ground)
17 High coolant temperature indication Open circuit Low (ground)
18 Low engine oil pressure indication Open circuit Low (ground)
19 Presence of water in fuel indication Open circuit Low (ground)
20 Overloaded or runaway engine indication Open circuit High (+B)
21 Not connected -
22 Not connected -
23 Reception of data from main panel NMEA communication protocol (0 to 5 V)
24 Transmission of data to secondary panel NMEA communication protocol (0 to 5 V)
