5
INSTALLATION DIRECTIVE
N45 MNA M10
N67 MNA M15
MAY 2006
1. IDENTIFICATION DATA
Figure 1
The engine identification data are stenciled on a tag positioned aside the coolant tank.
04_404_N
Figure 2
The last two figures of the commercial code refer to the
engine model (detail A or B in figure n. 2).
Until the beginning of the year 2006 the engines produced
had the code N45 MNA M10.00 or N67 MNA M15.00
(detail A in figure n. 2).
During the year 2006 relevant modifications have been made
to the electric system and to the fuel supply circuit and a new
model identified with the code N45 MNA M10.01 or N67
MNA M15.01 was created (detail B in figure 2).
This document concerns both the models. The relating
contents are developed in different chapters which can
be identified thanks to the presence in each title of the
extension M10.00/M15.00 or M10.01/M15.01.
Chapters 21 to the end of the document are common to
both the models.
