Iveco N67 MNA M15

INSTALLATION DIRECTIVE
33
MAY 2006
N45 MNA M10
N67 MNA M15
Electrical equipment component code
A drive shaft sensor (on request)
AC battery
AQ engine shut-off push-button on main panel
AS engine shut-off push-button on secondary panel
B drive shaft sensor (on request)
C emergency shut-down push-button
(optional, installer’s responsibility)
CA key switch
CS engine start push-button on secondary panel
EC
injection pump connector
GG connector for alternator
I high coolant temperature sensor (for alarm)
I1
KSB refrigerating liquid temperature sensor
J1 engine stop solenoid valve
J1
alternator excitation
K air filter clogging sensor (for alarm)
KSB
cold injection advance adjustment device
L instrument panel light switch
M sensor for detecting the presence of water in
the fuel pre-filter (for alarm)
MM electric starter motor
MS IVECO MOTORS indications and alarms module
O exhaust gas temperature sensor (on request)
P1 sound alarm inhibition push-button
QP main analog instrument panel
QS secondary analog instrument panel
SA buzzer
T coolant temperature sensor (for gauge)
V oil pressure sensor (for gauge)
W low oil pressure sensor (for alarm)
W
signal for revolution counter
Connectors
JA connection between engine wiring and interface
wire harness
JB on engine wire harness
set for connection to the main analog
instrument panel
JC on main analog instrument panel
set for connection to the engine wire harness
JD IVECO MOTORS indications and alarms module
JE on main analog instrument panel
set for connection to the secondary analog
instrument panel
JF relay box
JH on secondar y analog instrument panel
set for connection to the main analog
instrument panel
Indicator lights
EDC EDC malfunction
SAC presence of water in fuel pre-filter
SATA coolant high temperature
SBLA low coolant level
SBPO low oil pressure
SCP pre-post heating
SIFA clogged air filter
SIFB clogged oil vapor filter
SIFC clogged fuel filter
SIFO clogged oil filter
SP pre-lubrication
SS alternator fault
SSV engine overspeed
Gauges
CG revolution-counter
MO engine oil pressure
TA engine temperature
V voltmeter
Relays contained in the relay box
R1 power supply to terminal 50 of the electric
starter motor
R2 emergency engine shut-down provision
R3 key switch electric discharge
Fuses contained in the relay box
FS 2 on solenoid valve supply line for engine stop
FS 3 on main supply line
